Autodesk Inventor shifts the whole model after the huge delay.The correct transformation does not occur whatever point we tried to pull. AutoCAD is not able to cope with the problem.Let’s try to transform the object by pulling the point. The CPU time is around 45%, evenly distributing the load across all cores. At any time you can return to the starting point and get the original drawing. Please note that an object changes happen only in the part of the drawing that is transformed while the rest of the drawing remains unchanged - such a behavior is expected. Cheetah Solver, being connected to the AutoCAD 2015 transforms the demo model quickly and correctly.For other initial conditions it starts to show problems, sometimes the model freezes and sometimes the result would fail to meet the constraints. Under certain initial conditions (pull on the upper left corner), the program has a small delay and smoothly transforms drawing, allowing even return to the original position. PTC Creo Parametric 3.0 among all tested program works most correctly.But the work cannot be considered correct even for such a small model: the huge delay, the shift instead of transformations and unpredictable behavior - all, as in previous programs. The most what I managed to achieve - 2 objects, that is, 1/3 of the demo task. SolidWorks 2013 had a problem to draw a complete demonstration model of 6 objects.Predict the behavior of Solid Edge ST7 on this model is impossible.
Sometimes there are shifts instead of transformation. The first transformation is correct albeit with a long delay, but then drawing "stuck", the mouse movement has no effect.
Solid Edge ST7 shows a different behavior.And as is the AutoCAD case, the CPU load is 19%. Even without the 12 seconds delay, the behavior of Autodesk Inventor is not healthy for this model. Return to the starting position is impossible. When dragging the point further we noted an interesting effect - sometimes drawing is transformed, and sometimes, as in AutoCAD, there is just a shift of the entire drawing (it always happens during the drag down). Autodesk Inventor was able to transform the drawing as expected when we tried to pull up at the top left corner, but with a huge delay (about 12 seconds).The only one core is involved, not all available physical (four) and logical (eight) cores. We also noted that at the time of calculating the CPU load is not more than 19% (including a running program for screen recording). We never been able to see the expected result while using AutoCAD. the initial condition, the drawing may get stuck or do not move at all. Depending on the choice of the point for which you pull, i.e.
#GEOMETRIC CONSTRAINTS AUTODESK INVENTOR PRO 2015 FULL#
When you try to pull the corner of the object - instead of the expansion / contraction you see the full shift, that is, the resulting system of equations cannot be properly resolved. AutoCAD unable to adequately transform the drawing.Look at the behavior of the test program: We will try to expand or reduce the size of objects, while maintaining the constraints.
